Adams Rite Electric Strike Solenoid

Strike accepts bolt of any adams rite 4500 4700 discontinued or 4900 deadlatch or cylindrical latches.

Adams rite electric strike solenoid.

Strike accepts bolt of adams rite 4500 4700 discontinued or 4900 deadlatch or cylindrical locksets. The 7130 electric strike will be required to cover the strike opening or cutout in the frame. For a fail secure electric strike when no power is applied the shuttle keeps the latch arm in the unlocked position. 5 8 x 1 7 16 x 1 2 deep 15 9 mm x 36 5 mm x 12 7 mm deep.

Bolt retaining keeper is stainless steel. 7400 series electric strikes open electrically under 25 lbs 11 3 kg of preload. 1 2 to 5 8 12 7 mm to 15 9 mm preload. 74r1 electric strike is designed for rim exit devices with 3 4 19 1 mm pullman latchbolts for use in aluminum hollow metal or wood applications.

Open electrically under 25 lbs 11 3 kg of preload. From basic cost efficient grade 1 electric strikes to the premium preload capable ultraline series and with an. 1391 solenoid bolt pdf 122 kb 1354 mortice electro shear magnet pdf 369 kb 1354 surface electro shear magnet pdf 161 kb. The new adams rite p8800 p8700 pullman rim exit devices offer an exciting new solution for narrow stile aluminum applications.

Basic strike has lip of proper length for 1 3 4 44 5 mm thick door that closes flush with jamb edge. The existing mortise cylinder on the exterior of the door can be used on the 4900 deadlatch without any changes. The adams rite 7100 series electric strike operates using the solenoid located on a shuttle that slides to either lock or unlock the jaw when power is applied. Adams rite offers a rounded range of electric strikes compatible with deadlatches cylindrical and mortise locksets and pullman and interlocking rim exit devices in aluminum hollow metal and wood applications.

Grade 1 certified for the ultimate in strength and secruity available with an array of essential mechanical and electrification options and with a wide selection of compatible products to complete your solution. Solenoid electric latch retraction and motorized latch retraction available for all 8000 3000 adams rite exit devices the el option for rim exit devices and lr option for all other exit devices non rim exit devices use a solenoid mounted under the pushbar for instantaneous unlocking and locking of the exit device from a remote location or. Solenoid bolts fitting instructions. A 4900 paddle or any style of adams rite latch handle will be needed for the interior side of the door.

Adams rite is a trading division of assa abloy. 74r2 electric strike is designed for narrow stile rim exit devices with 1 2 12 7 mm pullman latchbolts designed for use in aluminum applications.
